CAEL 404 4WD Tractor 40 HP LS-EPA – Base Model

Name: CAEL 404 4WD Tractor 40 HP LS-EPA – Base Model
Brand: CAEL
Price: 24499.0 EUR
Availability: InStock

40engine HP

Openoperator station

—model year

€24.499,00VAT included. Shipping calculated at checkout.

Secure paymentEncrypted Shopify checkout
Delivery in 9 to 14 business daysEU: €10, or €500 by freight · United States: €14, or €1,000 by freight
5-year warranty5-year manufacturer warranty · statutory warranty included
14 days to change your mindStatutory right of withdrawal for consumers

In detail

Everything you need to know.

Description

The CAEL 404 4WD Tractor is a compact, capable 40 HP agricultural tractor for dependable performance and practical versatility across farming and utility work. It combines an LS-EPA engine and a 4WD drivetrain with an 8+8 gear synchronizer transmission, hydraulic steering, three-point suspension and a 540/1000 RPM PTO. Compact dimensions and an adjustable wheel track add maneuverability.

Key Features

40 HP (29.4 kW) L3CRV-T4 LS-EPA engine, 3-cylinder, water-cooled, 1.9 L
4WD drivetrain for strong traction
8+8 gear synchronizer transmission (forward 2.46–32.73 km/h, reverse 2.15–28.69 km/h)
9-inch dual-stage clutch
Full hydraulic steering and disc-type brakes
Category I three-point suspension with a lifting capacity of 7800 N at 610 mm behind the lift point
540/1000 RPM PTO with 6-Ø35 rectangular spline
Radial tires: 260/70R16 front, 320/85R24 rear
2-in / 2-out hydraulic valve, high-pressure lifter and quick coupling
Upper and lower drawbars, front fenders, ROP sunshade, LUX seat
31 × 2 rear weights

Optional Cab Configurations

Air-conditioned cab
Heated cab

Technical Specifications

Category	Parameter	Specification
Tractor	Model	404
Tractor	Drive Type	4WD
Tractor	Overall Dimensions	3180 × 1560 × 2400 mm
Tractor	Front Wheel Track	1000–1500 mm
Tractor	Rear Wheel Track	1000–1500 mm
Tractor	Wheelbase	1800 mm
Tractor	Ground Clearance	280 mm
Tractor	Rated Traction Force	7800 N
Tractor	Construction Mass	1600 kg
Tractor	Forward Speed	2.46–32.73 km/h
Tractor	Reverse Speed	2.15–28.69 km/h
Engine	Model	L3CRV-T4
Engine	Type	3-cylinder vertical, water-cooled, 4-stroke cycle
Engine	Rated Power	29.4 kW / 40 HP
Engine	Rated Speed	2600 rpm
Engine	Bore × Stroke	87 × 90 mm
Engine	Displacement	1.9 L
Drive System	Clutch	9-inch dual-stage
Drive System	Gearbox	8+8
Tires	Front	260/70R16 radial
Tires	Rear	320/85R24 radial
Steering	Steering System	Full hydraulic steering
Brakes	Brake Type	Disc type
Hydraulic System	Lifting Capacity	7800 N at 610 mm behind lift point
Suspension	3-Point Suspension	Category I
PTO	PTO Speed	540/1000 rpm
PTO	Spline Size	6-Ø35 rectangular spline
Optional	Cab	Air-conditioned cab / heated cab

Technical specifications

Model	CAEL 404 4WD Tractor 40 HP LS-EPA – Base Model
Engine power	40 HP
Operator station	Open platform
Full spec sheet	Detailed spec sheet on request

Delivery & setup

Machines are delivered by freight carrier by appointment: 9 business days for France and the EU, 14 business days for the United States. Orders under €10,000: €10 (EU) or €14 (United States); from €10,000: €500 (EU) or €1,000 (United States). Inspect the machine in the driver's presence and note any reservations on the delivery slip.

Payment

Encrypted payment through Shopify checkout; available payment methods are shown at checkout. For multiple machines or a business purchase, request a quote.

Warranty & returns

2-year statutory warranty of conformity and a 14-day right of withdrawal for consumers. 5-year manufacturer warranty. To return a bulky machine, please contact us first: we'll tell you the cost and arrange the pickup.

Compare

Versus similar models.

	CAEL 404 4WD Tractor 40 HP LS-EPA – Base Model This model	CAEL 404 4WD Tractor 40 HP LS-EPA – Front Loader	CAEL 404 4WD Tractor 40 HP LS-EPA – Loader & Backhoe	CAEL 504 4WD Tractor 50 HP with Cab – Base Model
Power	40 HP	40 HP	40 HP	50 HP
Operator station	Open	Open	Open	Cab
Price	€24.499,00	€27.999,00	€31.999,00	€26.499,00
		View	View	View
