CAEL 1.5 Ton Electric Reach Truck – 5 m Lift, 550 mm Reach

Shoptracteur · Implement & attachment

CAEL 1.5 Ton Electric Reach Truck – 5 m Lift, 550 mm Reach

$20,590.50Excluding VAT. Shipping calculated at checkout.

Bank transfer acceptedOrder, make the transfer, then email the proof to shoptracteur@gmail.com. We confirm receipt of payment and ship your order. Learn more
Secure paymentEncrypted Shopify checkout
Delivery in 9 to 14 business daysEU: €10, or €500 by freight · United States: €14, or €1,000 by freight
5-year warranty5-year manufacturer warranty · statutory warranty included
14 days to change your mindStatutory right of withdrawal for consumers

In detail

Everything you need to know.

Description

The CAEL 1.5 Ton Electric Reach Truck is a compact warehouse forklift for racking systems, narrow aisles, distribution centers, factories and pallet storage. It lifts 1.5 t (3300 lbs) to a maximum height of 5 m (16 ft 4 in).

Its compact chassis and forward reach system allow precise pallet placement into racks while keeping excellent maneuverability in tight aisles.

Key Features

Capacity up to 1.5 t / 1500 kg / 3300 lbs for pallets, cartons, industrial goods and inventory loads
5 m / 16 ft 4 in lift height, suited to taller shelving systems
550 mm reach distance for easy pallet insertion and retrieval
Compact design for narrow-aisle operation
Dual motor system: AC drive motor for efficient travel, DC hoist motor for dependable lifting power
Electric powered: quiet indoor operation with zero emissions

Specifications

Specification	Value
Type	Electric Reach Truck
Capacity	1.5 t / 3300 lbs
Load center	500 mm
Maximum lift height	5 m / 16 ft 4 in
Reach distance	550 mm
Weight (without battery)	2340 kg
Frame length (mast, no reach)	1780 mm
Overall length (mast, no reach)	2350 mm
Overall length (mast, reached)	2860 mm
Overall width	1035 mm
Overhead guard height	2180 mm
Mast lowered height	2200 mm
Fork length	1070 mm
Fork width	100 mm
Fork lowered height	55 mm
Turning radius	1710 mm
Minimum intersecting aisle width	2610 mm
Drive motor	AC motor – 1.5 kW
Hoist motor	DC motor – 3 kW
Battery	24V / 270Ah
Charger	110V

Applications

Warehouses
Distribution centers
High rack storage
Narrow aisle operations
Manufacturing plants
Inventory movement
Logistics facilities

What's Included

Battery 24V / 270Ah
110V charger

Technical specifications

Model	CAEL 1.5 Ton Electric Reach Truck – 5 m Lift, 550 mm Reach
Full spec sheet	Detailed spec sheet on request

Delivery & setup

Machines are delivered by freight carrier by appointment: 9 business days for France and the EU, 14 business days for the United States. Orders under €10,000: €10 (EU) or €14 (United States); from €10,000: €500 (EU) or €1,000 (United States). Inspect the machine in the driver's presence and note any reservations on the delivery slip.

Payment

Encrypted payment through Shopify checkout; available payment methods are shown at checkout. For multiple machines or a business purchase, request a quote.

Warranty & returns

2-year statutory warranty of conformity and a 14-day right of withdrawal for consumers. 5-year manufacturer warranty. To return a bulky machine, please contact us first: we'll tell you the cost and arrange the pickup.
